TUF B450 PRO GAMING AMD
Product Type:
Motherboards
Type Detail:
Intel Socket 1151 (1xx/2xx Chipset)
Manufacturer:
Asus
Manufacturer #:
90MB10C0-M0AAY0
Part Status:
Discontinued
Milwaukee PC SKU:
264119
Price:
$152.99

ASUS TUF B450-Pro Gaming AMD Ryzen 3 AM4 DDR4, HDMI, Dual M.2, USB 3.1 Gen 2 and AURA Sync RGB Lighting ATX Motherboard. Powered by 3rd & 2nd generation AMD Ryzen? AM4 processors, the ASUS TUF B450-PRO Gaming delivers 24/7 performance. Embrace reliability and stability with ASUS TUF Protection to ensure your components longevity by protecting Integrated DRAM, gigabit LAN , USB 3.1 Gen2 and graphic card deliver maximum connectivity speeds.

Quick Tech Specs

Processor Manufacture: AMD
Brand: ASUS
Chipset Manufacture: AMD
Form Factor: ATX
SLI Support: NONE
Crossfire Support: YES
Number of Memory Slots: 4 Slots
Max Memory: 64GB
Memory Type: DDR4
PCI Express x16 Slots: 3 Slots
PCI Express x1 Slots: 3 Slots
PCI Slots: None
WiFi Onboard: NONE
RAID Support: RAID 0/1/10
Sata 6 Gbits/s Ports (3.0/3.1): 6 Ports
Sata 3 Gbits/s Ports (2.0): None
Sata Express 16 Gbits/s Ports (3.2): None
M.2 Slots: 2 Slots
NVMe Support: No
eSata Ports: None
Legacy Ports: NONE
Thunderbolt Ports: NONE
USB 3.0 Ports: 2 Ports
USB 2.0 Ports: 2 Ports
Network Ports: Gigabit (10/100/1000)
Display Ports: NONE
DVI Ports: 1 Port
HDMI Ports: 1 Ports


Asus TUF B450 PRO GAMING AMD AM4, ATX


Form Factor

  • ATX Form Factor, 12.0 inch x 9.6 inch ( 30.5 cm x 24.4 cm )

CPU

  • AMD AM4 Socket for 3rd/2nd/1st AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics/Athlon™ with Radeon™ Vega Graphics Processors

Chipset

  • AMD B450

Memory

  • AMD Ryzen™ 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation Processors 4 x DIMM, Max. 64GB, DDR4 3533(O.C)/3466(O.C.)/3200(O.C.)/3000(O.C.)/2800(O.C.)/2666/2400/2133 MHz Un-buffered Memory Dual Channel Memory Architecture ECC Memory (ECC mode) support varies by CPU.

Graphics

  • Integrated Graphics in the AMD Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics Processors, Multi-VGA output support : HDMI/DVI-D ports - Supports HDMI 2.0b with maximum resolution of 4096 x 2160 @ 60 Hz - Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz

Multi-GPU Support

  • Supports AMD CrossFireX™ Technology

Expansion Slots

  • AMD Ryzen™ 2nd Generation/ Ryzen™ 1st Generation Processors: , 1 x PCIe 3.0/2.0 x16 (x16 mode), AMD Ryzen™ with Radeon™ Vega Graphics Processor: 1 x PCIe 3.0/2.0 x16 (x8 mode), AMD Athlon™ with Radeon™ Vega Graphics Processors: 1 x PCIe 3.0/2.0 x16 (x4 mode), AMD B450 chipset: 1 x PCIe 2.0 x16 (max at x4 mode), 3 x PCIe 2.0 x1

Storage

  • AMD Ryzen™ 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation Processors : 1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode), AMD Athlon™ with Radeon™ Vega Graphics Processors : 1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA mode), AMD Ryzen™ 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation Processors : 2 x SATA 6Gb/s port(s), Support Raid 0, 1, 10, AMD B450 chipset : 1 x M.2 Socket 3, with M Key, type 2242/2260/2280 storage devices support (PCIE 2.0 x4), 4 x SATA 6Gb/s port(s), Support Raid 0, 1, 10

LAN

  • Realtek® RTL8111H, TUF LANGuard

Audio

  • Realtek® ALC S1200A 8-Channel High Definition Audio CODEC, Audio Feature : - Exclusive DTS Custom for GAMING Headsets. - Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference - Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals - Premium Japanese-made audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity - Audio Cover: Effective shielding preserves the integrity of audio signals to ensure best quality.

USB Ports

  • AMD Ryzen™ 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation Processors : 2 x USB 3.1 Gen 1 port(s) (2 at back panel, , Type-A) AMD Ryzen™ 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation Processors : 1 x USB 3.1 Gen 1 port(s) (1 at back panel, , USB Type-CTM) AMD B450 chipset : 2 x USB 3.1 Gen 2 port(s) (2 at back panel, , Type-A) AMD B450 chipset : 2 x USB 3.1 Gen 1 port(s) (2 at mid-board) AMD B450 chipset : 6 x USB 2.0 port(s) (2 at back panel, , 4 at mid-board)

OS Support

  • Windows® 10 64-bit, Windows® 7 64-bit

Internal I/O Ports

  • 2 x Aura RGB Strip Header, 1 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin), 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s), 1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode), 1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (PCIE 2.0 x 4 mode), 6 x SATA 6Gb/s connector(s), 1 x CPU Fan connector(s) (1 x 4 -pin), 3 x Chassis Fan connector(s) (3 x 4 -pin), 1 x AIO_PUMP connector (1 x 4 -pin), 1 x S/PDIF out header(s), 1 x 24-pin EATX Power connector(s), 1 x 8-pin ATX 12V Power connector(s), 1 x Front panel audio connector(s) (AAFP), 1 x System panel(s), 1 x Clear CMOS jumper(s), 1 x COM port header

Back I/O Ports

  • 1 x PS/2 keyboard/mouse combo port(s), 1 x DVI-D, 1 x HDMI, 1 x LAN (RJ45) port(s), 1 x 5Gb/s port(s) USB Type-CTM , 2 x USB 3.1 Gen 2 (teal blue)Type-A, 2 x USB 3.1 Gen 1 (blue) Type-A, 2 x USB 2.0, 3 x Audio jack(s)

Special Features

  • ASUS TUF PROTECTION - ASUS SafeSlot: Protect your graphics card Investment - ASUS Overvoltage Protection: World-class circuit-protecting power design - ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability! - ASUS DIGI+ VRM: Precision control for stable power - ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges! AURA : - Aura Lighting Control - Aura RGB Strip Headers, ASUS Exclusive Features : - AI Suite 3 - Ai Charger - PC Cleaner, ASUS Quiet Thermal Solution : - Stylish Fanless Design Heat-sink solution & MOS Heatsink - ASUS Fan Xpert 4 Core, ASUS EZ DIY : - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode, ASUS Q-Design : - ASUS Q-Slot - ASUS Q-DIMM

Accessories

  • User's manual, I/O Shield, 2 x SATA 6Gb/s cable(s), 1 x M.2 Screw Package, 1 x Supporting DVD, 1 x TUF GAMING Sticker, 1 x TUF Certification card(s)
