AXE5400 Mesh Wi-Fi 6E

WiFi 6E offers the new 6 GHz frequency band with 1200 MHz of available spectrum. This wide-open band creates lower latency, higher throughput, and faster speeds for RE815XE. Enjoy the ultimate streaming experience with the latest WiFi generation.

RE815XE takes full advantage of tri-band, empowering up to 96 devices with lightning-fast 5400 Mbps speed. With the 6 GHz band serving as its backhaul, all of your connected devices receive phenomenal connectivity.

RE815XE's four external antennas create a stable wireless connection to any WiFi router, boosting your network's coverage. 6× high-power FEM provide maximum WiFi performance, so your phones and tablets stay connected as you move throughout your home. Beamforming technology detects the location of devices and concentrates WiFi towards them for stronger connections.

OneMesh™ enables RE815XE to network with any router that supports OneMesh™ to form a seamless roaming network system5 that shares a set of WiFi names for uninterrupted signal switching.

Highlights

• Working Modes: Range Extender/Access Point
• Ports: 1 Gigabit Ethernet Port
• Button: WPS Button, Reset Button
• Input Power: 100-240V~50/60Hz
• Power Consumption: 23W
• Antenna: 4 External Antennas
• Wireless Standards: IEEE 802.11ax 6 GHz, IEEE 802.11a/n/ac/ax 5 GHz, IEEE 802.11b/g/n/ax 2.4 GHz
• Frequency: 2.4GHz and 5GHz and 6GHz
• Signal Rate: 574 Mbps at 2.4 GHz, 2402 Mbps at 5 GHz, 2402 Mbps at 6 GHz
• Reception Sensitivity: 6GHz: 11ax HE20 MCS0:-92dBm, 11ax HE20 MCS11:-61dBm, 11ax HE40 MCS0:-89dBm, 11ax HE40 MCS11:-58dBm, 11ax HE80 MCS0:-86dBm, 11ax HE80 MCS11:-55dBm, 11ax HE160 MCS0:-83dBm, 11ax HE160 MCS11:-52dBm, 5GHz: 11ax HE20 MCS0:-93dBm, 11ax HE20 MCS11:-62dBm, 11ax HE40 MCS0:-90dBm, 11ax HE40 MCS11:-59dBm, 11ax HE80 MCS0:-87dBm, 11ax HE80 MCS11:-56dBm, 11ax HE160 MCS0:-84dBm, 11ax HE160 MCS11:-53dBm, 2.4GHz: 11ax HE20 MCS0:-95dBm, 11ax HE20 MCS11:-64dBm, 11ax HE40 MCS0:-92dBm, 11ax HE40 MCS11:-62dBm
• Wireless Functions: LED Control, Access Control, Power Schedule, Wi-Fi Coverage
• Wireless Security: 64/128-bit WEP, WPA/WPA-PSK2 encryptions, WPA3
• Transmission Power: FCC: 2.4GHz < 30dBm, 5GHz < 30dBm, 6GHz < 30dBm
• System Requirements: Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10, MAC OS, NetWare, UNIX or Linux, Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser
• Package Contents: Wi-Fi Range Extender RE815XE, Quick Installation Guide
