LANCOOL 216RW (White)

The LANCOOL 216 is a mainstream case that features all-around mesh panels for optimal airflow. Thanks to its modular rear panel, it can be optimized for air cooling or water cooling. It includes 2 x 160mm and 1 x 140mm pre-installed PWM fans and an innovative rear PCIe fan bracket to maximize airflow.

To ensure adequate airflow is provided to the system, the LANCOOL 216 features mesh at the front, top, and on the PSU shroud’s side. The front mesh extends to the top for a continuous mesh panel.

The included 160mm ARGB fans feature two channels of LEDs (one on the outer rim of the fan, another at the shaft of the fan blades) that can be controlled separately via an optional accessory, or via the motherboard lighting software by connecting them directly to a motherboard 5V 3pin header.

The modular motherboard I/O allow users to move the motherboard to a higher position which is more favorable for air-cooled systems, or a lower position for water-cooled systems.

Including a power button, reset button, audio port, 2x USB3.0 ports, and a USB Type C port, the front I/O module can be relocated to the lower left side of the front panel.

The LANCOOL 216 supports ATX, Micro-ATX, MINI-ITX motherboards, and E-ATX under 280mm in width (when the grommet bar is flipped 180°). In addition, thanks to its symmetrical design, cable management in the 2nd chamber remains unaffected.

The GPU placed at the top of the expansion slots in air cooling mode opens up the possibility to add a 120mm fan at the rear of the case without obstructing the GPU I/O. This is also possible with a vertically mounted GPU in both air-cooled and water-cooled mode. The additional 120mm fan provides better cooling for the GPU and a greater intake/exhaust balance for the system.

The top mounting bracket can be completely removed from the case for easier hardware installation. The bracket comes off with the left side frame bar to provide optimal clearance.

Highlights

• Form Factor: Mid-Tower
• MATERIAL: Steel / 4.0mm Tempered Glass
• MOTHERBOARD SUPPORT: E-ATX (Under 280mm)/ATX/Micro-ATX/Mini-ITX
• EXPANSION SLOT: 7
• DRIVES: Drive Cage:2 x 2.5” SSD + 2 x 3.5” HDD, PSU Cover:2 x 2.5” SSD, Behind MB tray: 2 x 2.5” SSD
• I/O: 1 x USB Type-C, 2 x USB 3.0, 1 x Audio combo jack, Power button, Reset button
• INCLUDED FANS: Front: 2 x 160mm ARGB Fans, Rear: 1 x 140mm PWM Fan
• FAN SUPPORT: Top: 3 x 120mm / 2 x 140mm, PSU Cover: 2 x 120mm / 2 x 140mm (Air Cooling mode), Front: 3 x 120mm / 2 x 140mm / 2 x 160mm, Rear: 1 x 120mm / 1 x 140mm (Not compatible with UNI FAN SL-INF 140), PCIe Fan Bracket: 1 x 120mm
• RADIATOR SUPPORT: Front: 360 / 280 / 240mm, Top: 360 / 280 / 240mm, Bottom: 240mm
• PSU SUPPORT LENGTH: ATX (Under 220mm)
• GPU LENGTH CLEARANCE: 392mm (max)
• CPU COOLER HEIGHT CLEARANCE: 180.5mm (max)
• DUST FILTERS: 1 x Bottom
• Mid-tower chassis configurable for air cooling and water cooling
• Front I/O that can be relocated to the bottom
• Includes rear PCIe fan bracket
