TD500 Mesh V2 White
TD500 Mesh V2 s iconic polygonal design paired with the included three 120mm ARGB fans engulfs your system in an ever-changing glow, shifting based on the angle viewed to reflect the uniqueness of each gamer s personality. Cooler Master s FineMesh provides the functionality of dust filtration while simultaneously allowing for generous intake and the ultimate experience: smooth running graphics, rapid response rates and blissfully streamlined gaming. Upgraded with USB 3.2 Gen 2 Type C support, TD500 Mesh V2 keep your data transfer at lightning speeds as you power through and play with style.
Polygonal FineMesh features a 3D contour and is also capable of simultaneously providing high airflow and dust filtration.
Pre-installed CF120 ARGB fans provide ample airflow, ensuring low temperatures, high performance, and eye-catching aesthetics during even the most intense gaming sessions.
USB 3.2 Gen 2 Type C port built into the I/O panel allows multipurpose, streamlined data transmission.
The included controller allows users to manage systems lighting independently from the hardware configuration and provides the user with 4 additional fan headers in case of need.
The top panel is entirely removable for Improved access during assembly and ease of mounting of cooling solutions.
Featuring a crystalline tempered glass side panel, completely toolless for quick access to the internals.
MasterBox TD500Mesh V2 is natively compatible with ITX, M-ATX and ATX motherboards.
E-ATX motherboards, such as SSI-CEB models, are compatible with dimensions up to 12”x 10.7".
Highlights
- Form Factor: Mid-Tower
- Materials - Exterior: Steel, Mesh, Plastic
- Materials - Left Side Panel: Tempered Glass
- Motherboard Support: Mini ITX, Micro ATX, ATX, SSI CEB, E-ATX*, (*up to 12" x 10.7" motherboards, may impact cable management feature)
- Expansion Slots: 7
- I/O Panel - USB Ports: 2 x USB 3.2 Gen 1, 1 x USB 3.2 Gen 2 Type C
- I/O Panel - Audio In / Out: 1 x Audio Jack
- I/O Panel - Other: 1 x ARGB Fan Hub
- 3.5" Drive Bays: 2
- 2.5" Drive Bays: 3
- Pre-installed Fans - Front: 3 x 120mm CF120 ARGB
- Fan Support - Top: 3 x 120mm, 2 x 140mm
- Fan Support - Front: 3 x 120mm, 2 x 140mm
- Fan Support - Rear: 1 x 120mm
- Radiator Support - Top: 120mm, 140mm, 240mm, 280mm, 360mm, (recommended maximum thickness -55mm)
- Radiator Support - Front: 120mm, 140mm, 240mm, 280mm, 360mm
- Radiator Support - Rear: 120mm
- Clearance - CPU Cooler: 165mm/6.49"
- Clearance - PSU: 200mm, (Recommended up to 170mm)
- Clearance - GFX: 410mm / 16.14"
- Cable Routing - Behind Motherboard Tray: 19mm / 0.74"
- Dust Filters: Front, Top, Bottom
- Power Supply Support: Bottom Mount, ATX
- Warranty: 2 Years
