Cooler Master HAF 500 (Black) High Airflow - ATX, no PS, ARGB, TG
Product Type:
Type Detail:
Cooler Master
Manufacturer #:
Part Status:
Current Stock
Milwaukee PC SKU:

Quick Tech Specs

Form Factor: ATX
Type: Mid Tower
Brand: Cooler Master
P.Supply Wattage: NONE
P.Supply Incl.: NONE
P.Supply Location: Bottom
Expantion Slots: 7 Slots
External 2.5" Bays: NONE
External 5.25" Bays: NONE
External 3.5" Bays: NONE
Internal 2.5" Bays: 2 Bays
Internal 3.5"/2.5" Bays: 2 Bays
Front USB-C: 1-Port
Front USB 2.0 Ports: NONE
Front USB 3.+ Ports: 2 Ports
Material: Steel
Window: YES
80mm Fans: NONE
90/92mm Fans: NONE
120mm Fans: 2 Fans
140mm Fans: NONE
200+mm Fans: 2 Fans

Cooler Master HAF 500 - Black

Cooler Master’s classic HAF series is making a return with HAF 500. Built for high airflow and peak performance, the HAF 500 boasts iconic 200mm large intake ARGB fans, ensuring unparalleled intake and cooling efficiency. The chassis features a dedicated GPU fan, adjustable to various GPU lengths. Ample clearance for dual 360mm radiators on the top and front panel accommodates the most advanced water cooling setups.

Tool-less side panels and a removable top panel facilitates simplified, hassle-free component installation without the need to struggle with small spaces.


  • Size: Mid-Tower
  • Materials - Side Panel Tempered Glass, Steel
  • Motherboard Support - ITX, Micro ATX, ATX, SSI CEB, E-ATX*, (*up to 12" x 14.1", may impact cable management and case features, remove cable cover and GPU fan bracket features)
  • Expansion Slots: 7
  • I/O Panel: 2x USB 3.2 Gen 1 (formerly USB 3.0), 1x USB 3.2 Gen 2 Type-C, 1x single Audio Jack, 1x Reset/ARGB button
  • ARGB Controller: ARGB Hub
  • Drive Bays: 2 x 2.5" or 2.5" / 3.5" Drive Bays (Combo)
  • Pre-installed Fans - Front 2x 200mm ARGB Fan
  • Pre-installed Fans - Rear 1x 120mm SickleFlow PWM ARGB
  • Pre-installed Fans - Top on HDD cage 1x 120mm SickleFlow PWM (GPU Fan)
  • Fan Support - Top - 3x 120mm, 2x 140mm, 2x 200mm
  • Fan Support - Front - 3x 120mm, 2x 140mm, 2x 200mm, *200mm Mounting Hole Spacing 154 x 154 w/ up to 30mm thickness
  • Fan Support - Rear 1x 120mm
  • Fan Support - Top on HDD cage 1x 120mm
  • Radiator Support - Top 120mm, 140mm, 240mm, 280mm, 360mm
  • Radiator Support - Front 120mm, 140mm, 200mm, 240mm, 280mm, 360mm
  • Radiator Support - Rear 120mm
  • Clearance - CPU Cooler 167mm/6.5"
  • Clearance - PSU 180mm/7.1"
  • Clearance - GFX 410mm/16.1"
  • Cable Routing - Behind Motherboard Tray 30mm
  • Dust Filters - Top, Bottom
  • Power Supply Support - Bottom Mount, ATX
  • Warranty - 2 years
