Cooler Master NR200 White SFF, mITX, No PS, 2xFans
Product Type:
Cases
Type Detail:
Mini-ITX
Manufacturer:
Cooler Master
Manufacturer #:
MCB-NR200-WNNN-S00
Part Status:
Special Order Only
Milwaukee PC SKU:
57284
Price:
$119.99

Quick Tech Specs

Type: Small Form Factor
Form Factor: Mini ITX
Brand: Cooler Master
P.Supply Wattage: NONE
P.Supply Location: Bottom
P.Supply Incl.: NONE
Expantion Slots: 3 Slots
External 2.5" Bays: NONE
External 3.5" Bays: NONE
External 5.25" Bays: NONE
Internal 2.5" Bays: 3 Bays
Internal 3.5" Bays: 2 Bays
Internal 3.5"/2.5" Bays: 1 Bay
Front USB 3.+ Ports: 2 Ports
Front USB 2.0 Ports: NONE
Material: Steel
Window: NONE
80mm Fans: NONE
90/92mm Fans: 1 Fan
120mm Fans: 1 Fan
140mm Fans: NONE
200+mm Fans: NONE
Warranty: 2 Years


Cooler Master NR200 White Mini ITX SFF

The MasterBox NR200 takes all of the features found in a core performance ATX chassis and efficiently utilizes them in a space less than half the volume. Every feature is thoughtfully laid out in the 18-liter case to maximize component compatibility, ease of use, and thermal efficiency. Open ventilation and multiple fan mounts bring airflow where it’s needed, while generous watercooling and aircooling clearances allow the fitment of coolers that can take advantage of all the airflow. Ample clearance for long, triple-slot graphics cards means no sacrifices are needed in GPU power to take advantage of small form factor sizing. The frame is wrapped in a sleek and tasteful steel chassis that blends in perfectly on top of desk.


Highlights

  • SIZE: Mini ITX
  • MOTHERBOARD SUPPORT: Mini DTX, Mini ITX, Max. size: 244 x 226mm
  • EXPANSION SLOTS: 3
  • 5.25" DRIVE BAYS: 0
  • 3.5" DRIVE BAYS: 1 (Max. 2)
  • 2.5" / 3.5" DRIVE BAYS (COMBO): 1
  • 2.5" DRIVE BAYS: 2 (Max. 3)
  • I/O PANEL: 2x USB 3.2 Gen 1 Type-A, 1x 3.5mm Headset Jack (Audio+Mic)
  • PRE-INSTALLED FANS - TOP: 1x 120mm 650-1800RPM PWM (SickleFlow)
  • PRE-INSTALLED FANS - REAR: 1x 92mm 650-2300RPM PWM (SickleFlow)
  • FAN SUPPORT - TOP: 2x 120mm
  • FAN SUPPORT - REAR: 1x 92mm
  • FAN SUPPORT - BOTTOM: 2x 120mm (recommended slim fans for GPUs wider than 2.5 PCI slots)
  • FAN SUPPORT - SIDE: 2x 120/140mm
  • RADIATOR SUPPORT - REAR: 92mm (not compatible with vertical GPU installation)
  • RADIATOR SUPPORT - BOTTOM: 120mm, 240mm, (recommended for custom loops only)
  • RADIATOR SUPPORT - SIDE: 120mm, 140mm, 240mm, 280mm, (not compatible with vertical GPU installation)
  • CLEARANCE - CPU COOLER: 155mm, 76mm (GPU in vertical position)
  • CLEARANCE - PSU: 130mm
  • CLEARANCE - GFX: L: 330mm (incl. power connector), H: 156mm (incl. power connector), W: 60mm (triple slot)
  • DUST FILTERS: Top, Bottom, Left side, Right side
  • POWER SUPPLY SUPPORT: SFX, SFX-L
  • WARRANTY: 2 years
