BNUC11TNKi30Z01

Highlights

• CPU: Intel® Core™ i3-1115G4 - 11th Gen - 2 cores/4 threads/6 MB Intel® Smart Cache
• CPU Speed: 3.00GHz up to 4.10GHz
• Board Number: NUC11TNBi30Z
• Graphics: Intel UHD Graphics
• Memory: No Memory
• Memory Supported: 2 x SODIMM, DDR4-3200MHz, Dual channel, up to 64 GB
• Storage: No HDD/SSD.
• Internal Drive Form Factor: M.2 SSD
• # of Internal Drives Supported: 2
• M.2 Card Slot (storage): 22x80 NVMe (M); 22x42 SATA (B)
• Audio: 7.1 Channel
• Graphics Output: Dual HDMI 2.0b w/HDMI CEC
• # of Displays Supported: 2
• # of USB Ports: 4
• USB Configuration: Front: 2 x USB 3.2, Rear: 1 x USB 3.2, 1 x USB 2.0, Internal: 1 x USB 3.2 on m.2 22x42 (pins), 2 x USB 2.0 (headers)
• Serial Port via Internal Header: Yes
• Integrated LAN: Intel® Ethernet Controller i225-LM
• Wireless Included: Intel® Wi-Fi 6 AX201 (Gig+)
• Bluetooth: BT 5.2
• M.2 Card Slot (wireless): 22x30 (E)
• Additional Headers: Front_panel (PWR, RST, 5V, 5Vsby, 3.3Vsby); Internal 2x2 power connector
• PCI Express Revision: Gen 4 (m.2 22x80 slot); Gen 3 (otherwise)
• PCI Express Configurations: PCIe x4 Gen 4: M.2 22x80 (key M), PCIe x1 Gen 3: M.2 22x42 (key B), PCIe x1: M.2 22x30 (key E)
• TDP: 15 W
• DC Input Voltage Supported: 12-20 VDC
• Chassis Dimensions: 117 x 112 x 37 [mm] (LxWxH)
• Board Form Factor: UCFF (4" x 4")
• Intel® Optane™ Memory Supported: No
• Intel® Virtualization Technology for Directed I/O (VT-d): Yes
• Intel® Virtualization Technology (VT-x): Yes
• Intel® Platform Trust Technology (Intel® PTT): Yes
• Intel® ME Firmware Version: 15
• Intel® AES New Instructions: Yes
• Supported OS: Windows 11 Home®, Windows 11 Pro®, Windows 10 Home®, 64-bit, Windows 10 IoT Enterprise®, Windows 10 Pro®, 64-bit, Red Hat Linux®, Ubuntu 20.04 LTS®
