Code Name Swift Canyon - Board Form Factor UCFF (4"" x 4"") - Socket Soldered-down BGA - Internal Drive Form Factor M.2 and 2.5"" Drive - # of Internal Drives Supported 2 - Embedded Options Available No - Lithography 14 nm - TDP 15 W - DC Input Voltage Supported 12-19 VDC - Board Chipset Intel Core? i5-6260U Processor (4M Cache, up to 2.90 GHz) - Description Other features: Includes SDXC card slot - Processor Included Intel Core? i5-6260U Processor (4M Cache, up to 2.90 GHz) - Max Memory Size (dependent on memory type) 32 GB - Memory Types DDR4-1866/2133 1.2V SO-DIMM - Max # of Memory Channels 2 - Max Memory Bandwidth 29.9 GB/s - Max # of DIMMs 2 - ECC Memory Supported ? No - Integrated Graphics ? Yes - Graphics Output Mini-DP 1.2 HDMI 1.4b - Intel Clear Video Technology Yes - # of Displays Supported ? 3 - PCI Express Revision Gen3 - PCI Express Configurations ? M.2 slot with PCIe x4 lanes - USB Revision 2.0 3.0 - # of USB Ports 6 - USB 2.0 Configuration (External + Internal) 0 + 2 - USB 3.0 Configuration (External + Internal) 2B 2F + 0 - Total # of SATA Ports 2 - Max # of SATA 6.0 Gb/s Ports 2 - Audio (back channel + front channel) 7.1 digital (HDMI mDP); L+R+mic (F) - Integrated LAN 10/100/1000 - Integrated Wifi Intel Wireless-AC 8260 + BT 4.1 - Integrated Bluetooth Yes - RAID Configuration 2.5"" SSD + M.2 SATA SSD (RAID-0 RAID-1) - Low Halogen Options Available See MDDS - Intel Virtualization Technology for Directed I/O (VT-d) ? Yes - Intel vPro Technology ? No - TPM No - Intel HD Audio Technology Yes - Intel Rapid Storage Technology Yes - Intel Virtualization Technology (VT-x) ? Yes - Intel AES New Instructions Yes
